Discover Tindall’s Latest Innovation:
T-SLAB


Precast concrete floor systems have been waiting for a revolution. With the new Tindall Superior Lightweight All-Purpose Beam (T-SLAB), that revolution has finally arrived. Come explore the benefits of this cutting-edge floor system and discover how T-SLAB could reshape your future projects.

What is T-SLAB?


T-SLAB is an all-new, patented precast concrete slab system that leverages the time-tested principles of Roman arch design and multiple concrete types to deliver a stronger, lighter, and more versatile slab. This groundbreaking product was designed to deliver all the advantages of concrete and the industry’s most effective building materials in a single, cost-effective, and 100% precast solution.

tindall t-slab precast concrete flooring system rendering

Benefits


T-SLAB offers a wide range of benefits to builders and architects alike, including the flexibility of cast-in-place concrete and improved structural performance compared to hollowcore. Unlike its competition, however, T-SLAB delivers all its benefits with the strength, speed, and performance of precast concrete.

Low Weight, Competitively Priced
  • High strength
  • Low weight
  • Approximately 50% of the total slab volume is lightweight concrete
  • More cost-effective to produce, transport, and install
  • Dampen natural frequency
  • Improves vibration
  • Enables up to 75% longer spans
Long Spans
  • Offers fixed-end capability over load-bearing walls or beams thereby increasing load/span capacity
Flexible Geometry
  • High degree of design flexibility
  • Unique shapes and features eliminate the need for cast-in-place
  • Round ends
  • Sharp ends
  • Geometry that fits building modules
  • Mechanical, Electrical, Plumbing Accommodation
  • Integral balconies
Up to 12' Widths
  • Reduces total installation costs
  • Simplifies construction process
  • Fewer crane lifts
  • Fewer visible joints
  • More flexibility for openings
Embeds
  • Can incorporate steel embeds and block-outs during production
  • Sleeves or embeds for safety rails
  • Bathroom drains
  • Standard/custom steel brackets
  • Extra reinforcement
  • Floor heating systems
  • Can accommodate Electric conduits and boxes
  • Projecting reinforcement for in-situ connections
Solid Zones
  • For embed steel plates and related items as may be required
  • Recesses for bath units
  • Full block-outs for HVAC
  • Solid zones with additional reinforcement can accommodate concentrated loads
  • Large holes with added reinforcement
Built in Bathrooms Embed
  • Eliminates installation on top of slabs and expensive floor structures
  • Reduces costs by eliminating in-situ slab coring or drilling
  • Enables faster schedules
Continuous Slabs
  • Reduces crane lifts by as much as 50–67% depending on bay configuration
  • Enables significantly faster installation
  • Reduces installation costs
Dapped Connections
  • Enables reduction in construction height
  • Reduces total structural depth
  • Improves interior/rebuilding possibilities
Balconies and Cantilevering
  • Built-in balcony solutions

How Does T-SLAB Work?


The T-SLAB is one of the latest examples of Roman building principles at work in the modern age. To produce a T-SLAB, Tindall first creates a series of lightweight concrete blocks, which allow prestressed reinforcement to be placed lengthwise and traditional reinforcement to be placed in the transverse direction. These blocks are then encased by self-compacting concrete, creating strong arches in a series of reinforced ribs. Where needed, the lightweight concrete blocks can be omitted, providing the flexibility to include ducts, built-in installations, and zones of solid concrete with added reinforcement.

Applications


When it comes to precast floor systems, T-SLAB is the ideal solution for a wide range of applications. Plus, T-SLAB empowers Tindall to easily convert existing designs to total precast. That means customers gain access to endless aesthetic options, a variety of precast finishes, unique architectural designs, and customization opportunities.

tindall office building icon

Offices

tindall dorm building icon

Dorms

tindall school building icon

Schools

tindall apartment building icon

Apartments

tindall buildings icon

Medium-Rise Buildings

tindall skyscraper icon

High-Rise Structures

How Does T-SLAB Stack Up?


The 100% precast T-SLAB enables fast construction schedules, provides remarkable design flexibility, creates exceptional architectural structures, and outclasses the competition at every turn.

HollowcoreDouble TeesCIPT-SLAB
No shoring and scaffolding tindall check icontindall check icontindall x icontindall check icon orange
Fast constructiontindall check icontindall check icontindall x icontindall check icon orange
Low floor heighttindall check icontindall x icontindall check icontindall check icon orange
Large width and fewer jointstindall x icontindall check icontindall check icontindall check icon orange
Smooth steel form ceiling finishtindall x icontindall x icontindall x icontindall check icon orange
Solid slab with no cores and reduced sound transmissiontindall x icontindall x icontindall check icontindall check icon orange
Solid endstindall x icontindall x icontindall check icontindall check icon orange
Flexible geometry and large openingstindall x icontindall x icontindall check icontindall check icon orange

Talk to Tindall

Every great project begins with a conversation. If you’re facing a design, timeline, or budget challenge, we’re happy to hear about it.
